as PDF WINNER of the UK Passivhaus Awards 2015 - The Cre8 Barn project is an innovative barn conversion to EnerPHit standard, which has transformed a derelict cow byre into an education centre for Yorkshire Wildlife Trusts Stirley Community Farm. The project features a box within a box structure (inner timber frame building within outer masonry barn) which preserves the outer appearance of the barn, while offering high levels of airtightness and continuity of insulation. The timber frame construction not only ensures thermal performance, but also helps provide structural stability to the outer masonry walls.
Cre8 Barn : Project images
Click on image to preview full size
Energy and fuel use
Measured data from renewable generation is not yet available.
Fuel use
| Pre-development | Forecast | Measured | |
| Electricity use | - | - | - |
|---|---|---|---|
| Natural gas use | - | - | - |
| Oil use | - | - | - |
| LPG use | - | - | - |
| Wood use | - | - | - |
| Other Fuel | - | - | - |
| Pre-development | Forecast | Measured | |
| Primary energy requirement | - | - | - |
|---|---|---|---|
| Annual CO₂ emissions | - | - | - |
| Annual space heat demand | - | 33 kWh/m².yr | - |
Renewable energy
| Electricity generation | Forecast | Measured |
|---|---|---|
| Renewables Technology | - | - |
| Other Renewables Tech | - | - |
| Electricity consumed by generation | - | - |
| Primary energy requirement offset by renewable generation | - | - |
| Annual CO₂ emissions offset by renewable generation | - | - |
Calculation and targets
| Whole house energy calculation method | PHPP |
|---|---|
| Other whole house calculation method | - |
| Energy target | EnerPHit |
| Other energy targets | - |
| Forecast heating load | 17 W/m² demand |
Airtightness
| Date | Result | |
| Pre-development air permeability test | - | - |
|---|---|---|
| Final air permeability test | - | 0.35m³/m².hr @ 50 Pascals |
Project description
| Stage | Occupied |
|---|---|
| Start date | 01 September 2012 |
| Occupation date | 01 September 2013 |
| Location | Huddersfield West Yorkshire England |
| Build type | Refurbishment |
| Building sector | Public |
| Property type | Detached |
| Construction type | Other |
| Other construction type | Box within a box timber frame within masonry |
| Party wall construction | |
| Floor area | 98 m² |
| Floor area calculation method | Treated Floor Area (PHPP) |
| Building certification |  Passivhaus certified building |
Project Team
| Organisation | Green Building Store Design & Build |
|---|---|
| Project lead person | |
| Landlord or Client | Yorkshire Wildlife Trust |
| Architect | Derrie OSullivan & Sue Heywood |
| Mechanical & electrical consultant | Green Building Company |
| Energy consultant | Green Building Company |
| Structural engineer | Stuart McCormick, SGM Structural Engineers |
| Quantity surveyor | |
| Consultant | Certifier - WARM: Low Energy Building Practice |
| Contractor |
Design strategies
| Planned occupancy | |
|---|---|
| Space heating strategy | |
| Water heating strategy | |
| Fuel strategy | |
| Renewable energy strategy | |
| Passive Solar strategy | |
| Space cooling strategy | |
| Daylighting strategy | |
| Ventilation strategy | |
| Airtightness strategy | |
| Strategy for minimising thermal bridges | |
| Modelling strategy | |
| Insulation strategy | |
| Other relevant retrofit strategies | |
| Contextual information |
Building services
| Occupancy | |
|---|---|
| Space heating | |
| Hot water | |
| Ventilation | |
| Controls | |
| Cooking | |
| Lighting | |
| Appliances | |
| Renewable energy generation system | |
| Strategy for minimising thermal bridges |
Building construction
| Storeys | 1 |
|---|---|
| Volume | - |
| Thermal fabric area | - |
| Roof description | Timber I beam with Gutex fibreboard and Earthwool Loft roll |
| Roof U-value | 0.10 W/m² K |
| Walls description | Timber I beam with Gutex fibreboard and Earthwool Frame therm |
| Walls U-value | 0.13 W/m² K |
| Party walls description | |
| Party walls U-value | - |
| Floor description | RC Slab with PIR insulation |
| Floor U-value | 0.11 W/m² K |
| Glazed doors description | Timber aluminium composite with thermal break |
| Glazed doors U-value | 0.78 W/m² K installed |
| Opaque doors description | |
| Opaque doors U-value | - - |
| Windows description | Timber aluminium composite with thermal break |
| Windows U-value | 0.78 W/m² K - |
| Windows energy transmittance (G-value) | 49 % |
| Windows light transmittance | - |
| Rooflights description | |
| Rooflights light transmittance | - |
| Rooflights U-value | - |
